Squareplug SP400

The Square Plug SP-400 is an ultra-low-profile right angle 6,3mm (1/4 inch) mono connector for cables of up to 4,8mm diameter.

Measurements: 8.3mm / 0.326" x 17mm / 0.67" x 28mm / 1.10".

Serviceable, all-metal plug designed to snug-fit smaller diameter cables for optimum strain relief and improved emi protection.

2 solder tabs for quick and easy soldering.

Insulation sheet to prevent hot and ground signals from shorting.

See the images section for a list of some of the compatible cables and equipment.

The SP-400 is compatible with any 4,8mm [0.155 inch] cable diameter or less.
Popular SP400-compatible cables include: Belden 1865A, Belden 8218, BTPA CA 0492, BTPA CA 0678, Bill Lawrence BL-150, Canare GS-4, Evidence Audio Monorail, Free the Tone CU-418, George L's 155, Lava Mini Tightrope, Mogami 2314, Sommer SC-ONYX TYNEE.

The SP400 plug is compatible with the following popular switching systems: VoodooLab Pedal Switcher, PX8, PX8 Plus, HEX, RJM PBC, Mini Effect Gizmo, MusicomLab 6M, 62M, 8L, MKIV, MKV, Providence Audio PEC-4V, PEC-2, IdeaBench Switcheroo, Carl Martin Octaswitch, Octaswitch mkii, Vinteck V8, Cusack Music: PBT9, PBT6 [Not Compatible with The GigRig G2 and Boss ES5/8].

Click here to download the Squareplug specs and compatibility list.

SKU SKU 49352

Weight 15,80 g

360 Image

Manufacturer KMMK SOLUTIONS SAS, 7 RUE DE CASTELLANE, 75008 Paris, Frankreich,contact@kmmk.solutions

Our price: €4,38
including VAT 19% , [plus shipping]
