Transformer T-PWR-45268-1

Output transformer for Fender Twin Amp (models made from 58-60). 4x6L6/5881, 4 Ohm. For High Power Tweed Twin, Twin Amp 5F8 - 6G8-A (= 125A4A). With additional 4 and 8 ohm taps! Made in USA. Attention: high induction, only to be used with low B+ voltages up to 450V!

Grand Stack = big tone
overall dimensions: W x H x D: B x H x T: 96 x 83 x 117 incl. shrouds
mounting on 82mm x 79-85mm (oblong hole)
Impedance: approx. 2.1k Ohm P-P

Primary:
A1 Blue
B+ Red
A2 Brown

Secondary:
16 Ohms Orange
8 Ohms Yellow
4 Ohms Green
0 Ohms Black
